Integrating PostgreSQL with .NET 9 Using EF Core: A Step-by-Step Guide

A Practical Example of Connecting an ASP .NET Core App to PostgreSQL using Entity Framework

PostgreSQL is the most popular database out there, according to the latest StackOverflow survey. And, of course, EF Core, as a versatile ORM, plays nicely with it. Still to integrate those two, one will need to make a few steps with a few caveats along the way. In this article, we will go through those steps together, implementing a couple of helper methods to make the integration even simpler in the future.

If you just want to use the simplified PostgreSQL connection, jump straight to the end of this article to the TLDR; section.

Setting Up the Project: Postgres Deployment with Docker Compose & Initial Raw Connection

To start, let's set up a local instance of PostgreSQL. Here's a simple compose.yml that does just that:

services:
  postgres:
    image: postgres
    environment:
      POSTGRES_DB: playground
      POSTGRES_USER: postgres
      POSTGRES_PASSWORD: postgres
    ports:
      - 5432:5432

After we've executed docker compose up -d and have our database up and running, let's scaffold our playground project. We'll use the most basic Minimal API template:

dotnet new web

Let's also make our logging a little bit nicer and remove app.Run() call since we don't actually need a running host:

builder.Logging.AddSimpleConsole(c => c.SingleLine = true); // added

// removed -> app.Run()

Most importantly, let's connect to the database. For now, we'll only need one package - PostgreSQL Provider for Entity Framework Core:

dotnet add package Npgsql.EntityFrameworkCore.PostgreSQL

With the package, we should be able to connect to the database we've deployed earlier. But first, we'll need a DbContext - let's declare an empty one:

public class Db(DbContextOptions<Db> options) : DbContext(options) {
}

Using the Db, we should be able to register our database in our DI container:

builder.Services.AddDbContext<Db>((sp, options) =>
{
  options.UseNpgsql("Host=localhost;Port=5432;Username=postgres;Password=postgres;Database=playground");
});

Finally, let's test our setup by logging a connection result. Here's a code that does just that:

await using var scope = app.Services.CreateAsyncScope();
var db = scope.ServiceProvider.GetRequiredService<Db>();
var canConnect = await db.Database.CanConnectAsync();
app.Logger.LogInformation("Can connect to database: {CanConnect}", canConnect);

Executing dotnet run should print Can connect to database: True in the console. And this is our setup - here's a complete Program.cs, just for reference:

var builder = WebApplication.CreateBuilder(args);

builder.Logging.AddSimpleConsole(c => c.SingleLine = true);

builder.Services.AddDbContext<Db>((sp, options) =>
{
    options.UseNpgsql("Host=localhost;Port=5432;Username=postgres;Password=postgres;Database=playground");
});

var app = builder.Build();

await using var scope = app.Services.CreateAsyncScope();
var db = scope.ServiceProvider.GetRequiredService<Db>();
var canConnect = await db.Database.CanConnectAsync();
app.Logger.LogInformation("Can connect to database: {CanConnect}", canConnect);

public class Db(DbContextOptions<Db> options) : DbContext(options) {
}

Connecting to the database is all good, but how about we do some SQL? Let's move straight to it in the next section.

First Query: Scaffolding our Database and Making an Example Request

To execute a proper SQL query, we'll need a table. Let’s scaffold a simple one, unoriginally called Records:

public class Db(DbContextOptions<Db> options) : DbContext(options) {
    public DbSet<Record> Records { get; set; } = null!;
}

public class Record
{
    public int Id { get; set; }
    public required string Name { get; set; }
}

For our experiments, we'll need a fresh database with tables created on every start. Here's how we can do that:

A friendly reminder to not use EnsureDeleted or EnsureCreated in a real application.

await db.Database.EnsureDeletedAsync();
await db.Database.EnsureCreatedAsync();

With the schema in place, let’s do the most basic operations of adding and reading our records:

db.Add(new Record { Name = "Test" });

await db.SaveChangesAsync();

var records = await db.Records.ToListAsync();

Now, after executing dotnet run, we should see the commands EF Core executed against our database:

INSERT INTO "Records" ("Name") VALUES (@p0) RETURNING "Id";
SELECT r."Id", r."Name" FROM "Records" AS r

Making a query was pretty, wasn't it? However, the query looks pretty ugly, with the quotes around each table and column name. Let's fix it in the next section!

Snake Case: Making EF Play Nicely with PostgreSQL

PostgreSQL has a rather hard preference for snake_case: If a column or table name is not snake case, PostgreSQL won't even recognize it, unless it is wrapped in quotes. EF Core, on the other hand, uses PascalCase by default. Of course, that misalignment will bring some pain when working with the PostgreSQL queries. Let's fix this by using a naming convention package:

dotnet add package EFCore.NamingConventions

With the package installed, we can update our DbContext registration to apply the snake_case naming convention. This ensures that all table and column names are automatically converted:

builder.Services.AddDbContext<Db>((sp, options) =>
{
    options.UseNpgsql("Host=localhost;Port=5432;Username=postgres;Password=postgres;Database=playground")
        .UseSnakeCaseNamingConvention();
});

Here's how our queries will look after the change:

INSERT INTO records (name) VALUES (@p0) RETURNING id;
SELECT r.id, r.name FROM records AS r

With our queries looking nice, it's time to address the next thing. If you are like me, it should already start bothering you to see the connection string hard-coded. Let's fix this in the next section.

Better Registration: Utilizing .NET Configuration System and Creating an Extension Method

Avoiding hard-coded connection string is pretty easy - we will read the value from the configuration instead:

builder.Services.AddDbContext<Db>((sp, options) =>
{
    var connectionString = builder.Configuration.GetConnectionString("Postgres");

    options.UseNpgsql(connectionString)
        .UseSnakeCaseNamingConvention();
});

Obviously, we will also need to set the value. Our code shouldn't change in a bit, regardless of the configuration source used, but as I explained in this article, my configuration source for such values is launchSettings.json, so here's the line we'll need to add:

"ConnectionStrings:Postgres" : "Host=localhost;Port=5432;Username=postgres;Password=postgres;Database=playground"

And here's how launchSettings.json should look in assemblance:

{
  "$schema": "https://json.schemastore.org/launchsettings.json",
  "profiles": {
    "http": {
      "commandName": "Project",
      "applicationUrl": "http://localhost:5267",
      "environmentVariables": {
        "ASPNETCORE_ENVIRONMENT": "Development",
        "ConnectionStrings:Postgres" : "Host=localhost;Port=5432;Username=postgres;Password=postgres;Database=playground"
      }
    }
  }
}

Now, by executing dontet run we should get exactly the same result as before. The code is fine now, but how about we make an extension method to make registration of our PostgreSQL database even smoother? Let's start by moving configuration resolution to a more flexible approach, avoiding dependency on WebApplicationBuilder.

Since our connection string is most likely required, we'll need an IConfiguration.GetRequiredValue method. Gladly, there's a package that provides such a method:

dotnet add package Confi

Now, we will resolve our IConfiguration from the DI container instead of relying on the WebApplicationBuilder. Here's the code:

var config = sp.GetRequiredService<IConfiguration>();
var connectionString = config.GetRequiredValue(configurationPath);

Using this approach, we should be able to assemble

using Confi;

// ...

builder.Services.AddPostgreDbContext<Db>();

// ...

public static class ServiceCollectionExtensions
{
    public static IServiceCollection AddPostgreDbContext<TContext>(this IServiceCollection services, string configurationPath = "ConnectionStrings:Postgres")
        where TContext : DbContext
    {
        return services.AddDbContext<TContext>((sp, options) => {
            var config = sp.GetRequiredService<IConfiguration>();
            var connectionString = config.GetRequiredValue(configurationPath);

            options.UseNpgsql(connectionString)
                .UseSnakeCaseNamingConvention();
        });
    }
}

Again, the results should be exactly the same as before, but with just a single simple line of code for registration. In the last section, you will find a quick recap of the article, along with some bonus, making PostgreSQL integration even easier.

Also, feel free to experiment on your own. You can find the complete code for this article here on GitHub.

TLDR;

In this article, we've implemented a helper method for seamless registration of a PostgreSQL database in a .NET application. Instead of recreating the method from scratch, you can use the Persic.EF package:

dotnet add package Persic.EF.Postgres

With the package installed, you will be able to attach your database with just a single line of code:

builder.Services.AddPostgres<Db>();

Of course, you would need to deploy the database first. Here's a simple compose.yml for that:

services:
  postgres:
    image: postgres
    environment:
      POSTGRES_DB: playground
      POSTGRES_USER: postgres
      POSTGRES_PASSWORD: postgres
    ports:
      - 5432:5432

Finally, don't forget to set your connection string to the ConnectionStrings:Postgres configuration value. My recommendation is to utilize launchSettings.json for that:

{
  "$schema": "https://json.schemastore.org/launchsettings.json",
  "profiles": {
    "http": {
      "commandName": "Project",
      "applicationUrl": "http://localhost:5267",
      "environmentVariables": {
        "ASPNETCORE_ENVIRONMENT": "Development",
        "ConnectionStrings:Postgres" : "Host=localhost;Port=5432;Username=postgres;Password=postgres;Database=playground"
      }
    }
  }
}

Here's a simple code snippet to test your connection:

await using var scope = app.Services.CreateAsyncScope();
var db = scope.ServiceProvider.GetRequiredService<Db>();
var canConnect = await db.Database.CanConnectAsync();
app.Logger.LogInformation("Can connect to database: {CanConnect}", canConnect);

This wraps up our PostgreSQL integration journey. This article, along with the Persic.EF.Postgres package, is part of a project called persic, containing various DB-related tooling. Check it out on GitHub and don't hesitate to give it a star! ⭐

Claps for this article are also highly appreciated! 😉
